Ventilation louvres, also known as air intake louvres or air exhaust louvres, are components used in building ventilation systems to control the flow of air. They are designed to allow fresh air to enter a building or room while preventing the entry of rain, debris, and other unwanted elements.
Our ventilation louvre systems support the principles of good building ventilation and airtightness, as outlined by the Australian Government’s YourHome guide. Proper ventilation — natural or mechanical — is essential for healthy indoor air quality and energy-efficient buildings.
ADA Louvres designs and manufactures high-quality ventilation louvres, engineered for plant rooms, mechanical ventilation, and architectural screening applications.
Our range includes single-stage, weather-resistant, and vertical blade louvre systems, offering the right balance of airflow, rain control, and visual screening for commercial and industrial projects.
All systems are custom-made in Adelaide using premium aluminium and designed to meet Australian Standards.
We offer a complete range of aluminium ventilation louvre systems to suit different performance requirements:
The 4537 louvre features a tight blade spacing to provide enhanced screening while maintaining strong airflow performance. It is commonly used where equipment needs to be concealed without compromising ventilation. It is a single-stage horizontal louvre with tight blade spacing (42 mm pitch) designed for increased visual screening while maintaining high airflow. Ideal for façade applications and plant areas where equipment concealment is important.
At a glance
Series depth: 45° blade, 42mm pitch (single-blade)
Free open area: Up to 60% free air (accessories reduce FOA)
Construction: Frame and blades manufactured from 6063-T5 aluminium, Bluescope Galvabond®, 304 stainless steel, or 316 stainless steel).
Finishes:
Aluminium: Mill finish, natural anodised, coloured anodised, or powder coated.
Bluescope Galvabond®: Mill finish or powder coated.
304 / 316 Stainless Steel: Mill finish
Options: Bird/vermin mesh, ganged modules, rear acoustic traps (on request)
Typical applications: Ideal for façade applications and plant screening
The 4560 louvre offers a balanced solution between airflow and visual screening, making it suitable for a wide range of general ventilation applications. With a 54 mm blade pitch, it provides improved coverage compared to larger pitch systems while still maintaining strong airflow performance. This single-stage horizontal louvre is commonly used in plant rooms, service areas, and mechanical enclosures where a combination of ventilation efficiency and moderate screening is required without the need for weather-resistant performance.
At a glance
Series depth: 45° blade, 54mm pitch (single-blade)
Free open area:55% minimum free air
Construction: Frame and blades manufactured from 6063-T5 aluminium, Bluescope Galvabond®, 304 stainless steel, or 316 stainless steel).
Finishes:
Aluminium: Mill finish, natural anodised, coloured anodised, or powder coated.
Bluescope Galvabond®: Mill finish or powder coated.
304 / 316 Stainless Steel: Mill finish
Options: Bird/vermin mesh, modular/ganged panels, rear acoustic traps
Typical applications: Plant rooms, mechanical service enclosures, car park ventilation openings, commercial building risers, warehouse ventilation panels
The 90100 louvre is a vertical blade system designed to deliver effective ventilation while achieving a clean, modern architectural appearance. Its vertical blade configuration naturally directs water downward along the façade, helping to reduce rain carryover compared to traditional horizontal louvres. With a 60 mm blade pitch, it provides consistent airflow and uniform screening, making it ideal for façade applications, plant screening, and projects where design aesthetics are a key consideration.
At a glance
Series depth: 60 mm pitch (vertical blade configuration)
Free open area: ~51% nominal (varies with accessories)
Construction: Frame and blades manufactured from 6063-T5 aluminium, Bluescope Galvabond®, 304 stainless steel, or 316 stainless steel).
Finishes:
Aluminium: Mill finish, natural anodised, coloured anodised, or powder coated.
Bluescope Galvabond®: Mill finish or powder coated.
304 / 316 Stainless Steel: Mill finish
Options: Bird/vermin mesh, ganged modules, rear traps
Typical applications: Architectural façades, plant screening, commercial buildings, service risers, modern building envelopes
The S45/100 louvre is a high airflow single-stage horizontal louvre designed for applications where ventilation performance is the primary requirement. Featuring a 100 mm blade pitch and a simple 45° blade profile, it allows maximum air movement with minimal resistance. This makes it a cost-effective and reliable solution for plant rooms, rooftop enclosures, and industrial ventilation openings where weather protection is not critical and airflow efficiency is the priority.
At a glance
Series depth: 100 mm (45° blade)
Free open area: ~55% nominal (accessory-dependent)
Construction: Frame and blades manufactured from 6063-T5 aluminium, Bluescope Galvabond®, 304 stainless steel, or 316 stainless steel).
Finishes:
Aluminium: Mill finish, natural anodised, coloured anodised, or powder coated.
Bluescope Galvabond®: Mill finish or powder coated.
304 / 316 Stainless Steel: Mill finish
Options: Bird/vermin mesh, ganged modules, rear traps
Typical applications: Plant rooms, rooftop enclosures, industrial ventilation openings, mechanical rooms, façade screening
The 45100S louvre is an enhanced single-stage system designed to improve rain performance while maintaining similar airflow to standard 100 mm pitch louvres. It incorporates a deeper blade profile and sharper leading edge, which helps break up and shed wind-driven rain more effectively. This makes it well suited to exposed or windward locations where a standard single-stage louvre may allow more water carryover, but a full two-stage system is not required.
At a glance
Series depth: 100 mm (45° blade, enhanced profile)
Free open area: ~55% nominal (before mesh/traps)
Construction: Frame and blades manufactured from 6063-T5 aluminium, Bluescope Galvabond®, 304 stainless steel, or 316 stainless steel).
Finishes:
Aluminium: Mill finish, natural anodised, coloured anodised, or powder coated.
Bluescope Galvabond®: Mill finish or powder coated.
304 / 316 Stainless Steel: Mill finish
Options: Bird/vermin mesh, ganged modules, rear traps
Typical applications: Windward façades, exposed plant rooms, rooftop installations, commercial buildings, external service areas
The 2S100 louvre is a two-stage horizontal system engineered to provide improved weather resistance while maintaining effective ventilation. By combining a front and rear blade stage, it creates a stepped airflow path that helps reduce rain penetration and enhances screening performance. This makes it ideal for rooftop plant enclosures, exposed façades, and mechanical areas where both airflow and protection from the elements are important design considerations.
At a glance
Series depth: 100 mm pitch (two-stage system)
Free open area: ~45% nominal (varies with accessories)
Construction: Frame and blades manufactured from 6063-T5 aluminium, Bluescope Galvabond®, 304 stainless steel, or 316 stainless steel.
Finishes:
Aluminium: Mill finish, natural anodised, coloured anodised, or powder coated.
Bluescope Galvabond®: Mill finish or powder coated.
304 / 316 Stainless Steel: Mill finish
Options: Bird/vermin mesh, ganged modules, rear traps
Typical applications: Rooftop plant enclosures, exposed façades, mechanical plant rooms, commercial buildings, areas requiring improved rain resistance
All ADA ventilation louvres are manufactured from high-quality Australian aluminium (6063-T5) as standard with optional steel construction.
Available finishes:
Mill finish
Natural anodised
Powder-coated (full colour range)
Coloured anodised
Optional inclusions:
Bird / vermin mesh
ADA louvre systems are engineered to meet Australian standards and project requirements.
Designed to AS 1170 (wind loading)
Aluminium design to AS 1664
Tested airflow and pressure drop performance
Custom engineering available
Note:
Standard single-stage louvres are not fully weatherproof and should be used with appropriate drainage and clearances.
General Ventilation
Plant rooms
Mechanical ventilation systems
Rooftop enclosures
Commercial façades
Equipment screening
